A106 Grade B Steel Pipe

ASTM A106 is suitable for seamless carbon steel pipe for high temperature environment. ASTM A106 pipe is manufactured according to grade A, B and C. A106-A is equivalent to the domestic 10# steel material, A106-B is equivalent to the domestic 20# material, is a relatively common use of a steel pipe material at home and abroad. A106 seamless steel pipe is mainly used in construction, mechanical processing, electrical, petrochemical and other industries.

Classification :

Carbon Steel Pipe

+8615376063736

sales@zyuansteelgroup.com

E-mail

PRODUCT DETAILS

Keywords: Steel Plate 、 Steel Coil

A106 Grade B Steel Pipe Description

Product Parameters

Product Name	A106 Grade B Steel Pipe
Standard	EN/DIN/JIS/ASTM/BS/ASME/AISI etc.
Outer Diameter	Seamless: 1/4"-36"	Welding: 21.3mm-3620mm
	Round Tube: 1/2"-10"	Square Tube/Rectangular Tube: 15x15mm-400x600mm
Wall Thickness	Seamless: 1.25mm-50mm	Welding: 1.65mm-65mm
Length	3-12 meters, Support customization
Surface Process	Bright, Polished, Black
Other Services	Machining(cnc), Centerless Grinding(cg), Heat Treatment, Annealing, Pickling, Polishing, Rolling, Forging, Cutting, Bending, Small Machining, etc.

Chemical Composition

A106	C	Mn	P	S	Si	Cr	Cu	Mo	Ni	V
GradeA	0.25	0.27-0.93	0.035	0.035	0.10	0.40	0.40	0.15	0.40	0.08
GradeB	0.30	0.29-1.06	0.035	0.035	0.10	0.40	0.40	0.15	0.40	0.08
GradeC	0.35	0.29-1.06	0.035	0.035	0.10	0.40	0.40	0.15	0.40	0.08

Mechanical Properties

A106	GradeA	GradeB	GradeC
Tensile Strength min.psi	48,000	60,000	70,000
Yield Strength min.psi	30,000	35,000	40,000

Scope of Application

ASTM A106 seamless pressure pipe (also known as ASME SA106 pipe) is commonly used in the construction of oil and gas refineries, power plants, petrochemical plants, boilers and ships. These pipes must transport fluids and gases with high temperature and pressure levels.

CUSTOMER VISIT

In ZYUAN, more than 180 steel grades have either been used to substitute import or produced with foreign standards, more than 30 steel grades have been exported many developed countries and regions in Europe, America and Asia, setting up mighty image of brand.

Customer photo

FACTORY WORKSHOP

ZYUAN STEEL GROUP CO.,LTD has been founded over 20 years. And ZYUAN has 12 product series, 300 and more steel grades, 400 and more thickness specifications steel pipes, sheet, coils and other products such as low alloy high strength steel products and alloy structural steel products etc.

TEST

FAQ

Once the products received by customer were found not comply with the products or contract demands, what will you do?

A: We will compensate the customer for all the loss without any hesitation.

Do you provide samples Is it free or extra?

A: Yes, we could offer free samples.

What certifications do your products have?

A: We have ISO 9001, SGS, EWC and other certifications.

What kind of payment terms would you accept?

A: We always do T/T.30% T/T as deposit,70% T/T as balance.

What is the delivery time?

A: 10-15 days

What is your MOQ?

A: We will provide Original Mill Usually 25 tonnes, but it can be adjusted according to your needs and the actual situation of the inventory.
